1-1 1-1 17110340500 Door inner frame, LH $204.01
1-2 1-2 17110340600 Door inner frame, RH $204.01
2-1 2-1 16610342200 Door outer handle, LH $53.54
2-2 2-2 16610343200 Door outer handle, RH $53.54
3-1 3-1 16614100070 Clamp, outer handle, LH $0.70
3-2 3-2 16614100090 Clamp, outer handle, RH $0.70
4 4 16614100100 Connecting rod $1.86
5-1 5-1 16510342100 Door lcok, LH $25.38
5-2 5-2 16510343100 Door lcok, RH $25.38
6 6 17110340910 Sealing strip,Glass door $16.92
7 7 17110340140 side door waterproof srip $11.21
8 8 17110340320 front door push-pull window $46.52
9 9 17110340310 front door upper window $126.88
10 10 17110340330 front door lower window $126.88
11 11 16510340240 door inner lock $3.09
12 12 16614100050 handle $3.17
13 13 16510340940 window mud track $2.11
14 14 17110341000 front window upper guide $7.19
15 15 17110341010 front window lower guide $8.46
16 16 17110340530 push-pull window cushion $1.35
17 17 17110341020 push-pull window lock $3.38
18 18 17110341030 push-pull window lock position plate $3.81
19 19 04512080127 hexagon rivet nut $0.70
20 20 04512060127 hexagon rivet nut $0.70
21 21 17110341040 window rubber cushion $0.70
22 22 06119061805 flat washer $0.70
23 23 03414060254 hexagon flange screw $0.70
24 24 04612050025 hexagon lock nut $0.70
25 25 03124040165 cross shape bolt $0.70
26 26 04312060014 cap nut $0.70
27 27 03414060164 hexaton flange screw $0.70
28 28 15105140000 rear view mirror (left) $19.03
28 28 15105150000 rear view mirror (right) $19.03
29 29 01224060305 hexagon flange bolt $0.70
30 30 16510340430 door strap $0.70
31 31 01254060166 hexagon flange bolt $0.70
32-1 32-1 17110340510 front door latch fixation plate (left) $6.77
32-2 32-2 17110340520 front door latch fixation plate (right) $6.77
33 33 01256100256 hexagon flange bolt $0.70
34 34 16510340490 latch $7.61
35 35 04212120021 hexagon flange nut $0.70
36 36 17110340531 Adjustable hinge (steel) $8.53
37-1 37-1 17110340711 Door hinge upper left (cast steel) $15.32
37-2 37-2 17110340811 Door hinge upper right (cast steel) $15.32
38 38 17210340721 Motionless hinge $8.29
39-1 39-1 17110340731 Door hinge lower left (cast steel) $13.73
39-2 39-2 17110340831 Door hinge right lower (cast steel) $13.73
40 40 07031101007 Snap ring (E type) $0.70
41 41 7031090004 Snap ring (E type) $0.70
42 42 1214080255 Hex Flange Bolt 8x25 $0.70
43 43 1224080405 Hex Flange Bolt 8x40 $0.70
44 44 4612080025 Heagon flange locking nut 8 $0.70
45 45 1224080305 Hex Flange Bolt 8x30 $0.70
46 46 1256100256 Hex Flange Bolt 8x25x1.25 $0.70
47 47 16510340520 Adjusting shim $1.27
48 48 17110341050 Front window rail sealing skin $2.96
49 49 06769061814 paper washer $0.70
50 50 03344080255 Hexagon socket cap screws M8x25 $0.70
Description
Desertcross 1000cc-6 HVAC Before the door
